Bacterial Cellulose ( BC ) ** is a high-purity β-1,4- glucose chain polymer synthesized by Gram-negative aerobic bacteria (mainly Komagataeibacter xylinus ) under specific culture conditions . Its three-dimensional nanofiber network structure, ultra-high crystallinity ( >80% ) and good biocompatibility make it have wide application potential in cutting-edge technologies such as biomedicine, flexible electronics and bionic materials.

Among all kinds of synthesis paths, static culture method has become the preferred experimental preparation method in current research and high-end applications due to its advantages in control of BC structural integrity and uniformity.

1. Static culture method mechanism and conditional control

The static culture method is based on the formation of an aerobic metabolic reaction microenvironment at the air --liquid interface of BC strains , which prompts them to synthesize cellulose microfiber filaments (diameter 20–100 nm ) and self-assemble into continuous films.

Key culture parameters:

parameter

Typical range

Technical Key Points

Culture temperature

28–30°C

Approximate the optimal enzyme activity area, promoting efficient catalysis of extracellular glucan synthase complex

Initial pH

5.0–6.0

Avoid the accumulation of by-product acids in carbon source metabolism, resulting in decreased yield

Carbon source concentration

20–50 g/L

Glucose, glycerin or waste molasses are commonly used options, which directly affects the synthesis rate.

Oxygen supply

Static gas -liquid interface diffusion

Oxygen is a key speed limit factor, and the design of the culture container must avoid excessive pressure on the liquid surface.

Cultivation cycle

7-14 days (film thickness 0.5~3mm)

Can control film thickness and crystallinity, suitable for different uses

2. Microstructure and performance analysis of BC membrane

The prepared by static culture method BC membrane showed high uniformity and good controllability in morphology and structure:

Typical characterization data (using SEM/TEM, XRD, TGA, FTIR, etc.):

Performance metrics

Static BC membrane data

Application Relevance

Nanofiber diameter

20–60 nm

Influence mechanical enhancement and cell adhesion ability

Specific surface area

80–120 m²/g

Determine adsorption and composite properties

Crystallization degree

≥ 80% (XRD analysis)

Determines mechanical strength and thermal stability

Decomposition temperature

280–320°C (TGA analysis)

Can be used in high temperature coatings or electronic packaging

Water content

≥ 90% (in situ wet)

Suitable for hydrogels, biostents and other scenarios

3. Process advantages and applicable directions of static cultivation method

Dimension

Description of the advantages of static cultivation

Controllable structure

The film has regular morphology and uniform thickness, making it easy to standardize film-level products

Minimum impurities

No lignin and hemicellulose, only NaOH boils + water washing after treatment

Low cost moderate

Simple primary production equipment, no large-scale stirring and fermentation system required

High adaptability

It can adapt to different scenarios through morphology regulation, such as tissue engineering membranes, battery separators, and coated substrates.

4. Technical bottlenecks and future directions

Current Challenge:

Limited yield : static systems have low output per unit volume and are susceptible to oxygen transfer efficiency;

The cost of carbon sources is relatively high : industrialization still relies on high-purity sugar sources, and agricultural by-product replacement needs to be explored;

Long culture cycle : Compared with stirring and fermentation, the production cycle is about 2 to 3 times longer;

Innovation Trends:

Technical path

describe

Synthetic Biological Strain Engineering

Using gene regulation pathways to improve glucan synthase expression and enhance yield

Multi-layer modular static system development

Build a large-scale cultivation platform for automatic temperature control and layered membrane extraction

Functional BC membrane development

Grafting carboxyl, amino, and conductive materials to achieve intelligent response and high conductivity

V. Conclusion

The static culture method has irreplaceable scientific and engineering value in basic research on bacterial cellulose, membrane-level product development and functional material exploration. In the future, through the integration of microbial engineering and materials science, prepared by static method BC will gradually achieve a leap from ' laboratory materials ' to ' industrial platform materials ' and serve a wider range of green manufacturing and high-end applications.
