Comparative analysis of the difference between CNCCNF and bacterial cellulose

Nanocellulose is a new material derived from natural cellulose, with the advantages of high strength, low density biodegradability, etc. It is widely used in packaging composite materials, medical dressings, flexible electronics and other fields. Common nanocellulose types include: cellulose nanocrystals ( CNC ) , cellulose nanofiber filaments ( CNF ) and bacterial cellulose ( BC ). This article will systematically compare the differences between the three nanocelluloses from the aspects of source structure performance and application.

Source and preparation of one or three types of nanocellulose

type

source

Preparation method

Environmental protection

CNC

Plant fibers such as wood pulp cotton

Remove amorphous regions by sulfuric acid hydrolysis

Acid solution needs to be processed

CNF

Wood pulp straw flax, etc.

High pressure homogenous grinding enzymatic lysis

Relatively green, high energy consumption

BC

Microorganisms such as acetate

Static or stirred liquid fermentation

Biological processes, environmentally friendly but costly

Comparison of two structural features and dimensions

type

Profile

Size range

Crystallization degree

CNC

Rigid rod-shaped crystals

3–20 nm width , 100–500 nm length

High ( 60–90%)

CNF

Flexible filament

Diameter 5–50 nm, length micrometers

medium

BC

Three-dimensional nano-network structure

Diameter 20–100 nm

Extremely high ( >80%)

Comparison of three physical properties

type

Mechanical properties

Thermal stability

Transparency

Dispersibility

CNC

High strength but brittle

Moderate, affected by sulfate groups

good

Stable suspension

CNF

Good flexibility

Stablize

generally

Easy to reunite, need to be dispersed ultrasonic

BC

Toughness and strength

Excellent

Extremely high

Natural gel structure

Four chemical properties and biosafety

type

Surface groups

Modification capability

Biocompatibility

CNC

–OH–OSO₃⁻ (Sulphate hydrolysis residue)

High, can be used for grafting and composite

good

CNF

–OH, partially introduced –COOH

High, suitable for water-based modification

good

BC

High purity hydroxyl group

Extremely high, suitable for biological functionalization

Excellent, widely used in the medical field

Five typical application areas

type

Application direction

CNC

Reinforced plastic transparent coating electronics

CNF

Food thickener medical gel functional paper

BC

Medical dressing artificial skin biofilm material flexible sensor

Suggestions on the selection of six or three types of nanocellulose

CNC is suitable for scenarios where rigidity requirements are high and composite materials need to be reinforced;

CNF is suitable for use in colloidal dispersion systems for flexible substrate foods;

BC is more suitable for high-end fields with biomedical food contact and high purity needs

Seven conclusion

Understanding the structural and performance differences between CNC CNF and bacterial cellulose will help make reasonable choices in scientific research and industrial production. With the continuous optimization of preparation technology, nanocellulose will play greater value in the fields of environmentally friendly materials biomedical and intelligent manufacturing.
